S2FP102 Safety Switch with Lock Function Electromechanic, Power to Lock Principle
Safety Switch with Lock Function
In Stock
$597.69
per unit
Applications: Safety Systems, Sensors & I/O
Description
The electromechanical safety switch with lock function is distinguished by a high locking force of 1150 N. This means that only one safety switch with locking function is required to attain the Cat. 4 PL e safety level (EN ISO 13849-1). The safety level, as well as the response time and risk time, remain unchanged when connected in series. Extensive diagnosis functions enhance system availability and simplify installation and maintenance. The unique star handle operating concept is especially well-suited for rotary and sliding doors.
Features at a Glance
- Power to lock principle
- Performance Level: Cat. 4 PL e
- Locking force of 1150 N
Technical Data
Electrical Data
| Sensor Type | Locking unit |
| Supply Voltage | 20.4 … 26.4 V DC |
| Response Time | ≤ 100 ms |
| Risk time | ≤ 200 ms |
| Temperature Range | 0 … 60 °C |
| Storage temperature | -10 … 90 °C |
| Safety Output | OSSD |
| Number of safety outputs (OSSDs) | 2 |
| PNP Safety Output/Switching Current | 250 mA |
| Number of Signal Outputs | 1 |
| PNP signal output switching current | 50 mA |
| Short Circuit Protection | yes |
| Protection Class | III |
Mechanical Data
| Housing Material | Plastic |
| Degree of Protection | IP67 IP66 IP69 |
| Connection | M12 × 1; 8-pin |
| Latching Force, typical | 25 / 50 N |
| Weight | 733 g |
Safety-relevant Data
| Operating principle | RFID |
| Coding | Standard |
| Performance Level (EN ISO 13849-1) | Cat. 4 PL e |
| PFHD | 5,20 × E-10 1/h |
| Safety Integrity Level (EN 61508) | SIL 3 |
| Safety Integrity Level (EN 62061) | SILCL 3 |
| PDDB (EN 60947-5-3) | yes |
| Locking Device | Power to lock principle |
| Locking force F (Zh) | 1,150 N |
General Data
| Applicable actuator | S2FP200 |
Function
| Series Connection | yes |
| Actuator monitored | yes |
| Mechanical Detent Mechanism | yes |
| Detent Mechanism | yes |
| Auxiliary release | yes |
