NI70-W80-OD6L-Q Inductive Sensor
Inductive Sensor, Rectangular housing W80, Switching distance 70 mm, Non-flush, IP67, -25…70 °C, 2-wire DC, Screw terminal
In Stock
$87.08
per unit
Applications: Sensors & I/O
Technical Data
| Connection | Terminal |
| Ambient temperature | -25 … +70 ℃ |
| Sensing surface material | PA |
| Sensing range | 70 mm |
| Housing material | PA |
| Switching frequency | 30 Hz |
| Supply voltage | 10 … 30 V DC |
| Load current | ≤ 100 mA |
| Output status | NO |
| Output type | DC |
| External dimensions | Square |
| Mounting | Non-flush |
| Product size | 80 x 80 x 40 mm |
| IP rating | IP67 |
