NI20-G18-CN6L-Q12 Inductive Sensor
Inductive Sensor, Threaded cylindrical housing M18, Switching distance 20 mm, Non-flush, IP68, -25…70 °C, NPN NC, M12 connector
In Stock
$33.12
per unit
Applications: Sensors & I/O
Technical Data
| Sensing range | 20 mm |
| Mounting | Non-flush |
| Connection | M12, 4-pin |
| Housing material | Nickel-plated brass |
| Sensing surface material | PBT |
| Switching frequency | 200 Hz |
| Supply voltage | 10 … 30 V DC |
| Ambient temperature | -30 … +85 ℃ |
| Load current | ≤ 200 mA |
| Output status | NC |
| Output type | NPN |
| External dimensions | M18 x 1 |
| Product size | M18 x 77 mm |
| IP rating | IP68 |
