Technical Data
Inductive Data
| Switching Distance |
2 mm |
| Switching Hysteresis |
< 15 % |
Electrical Data
| Supply Voltage |
10 … 30 V DC |
| Current Consumption (Ub = 24 V) |
< 20 mA |
| Switching Frequency |
800 Hz |
| Temperature Drift |
< 10 % |
| Temperature Range |
-25 … 70 °C |
| Number of Switching Outputs |
2 |
| Switching Output Voltage Drop |
< 2 V DC |
| Switching Output/Switching Current |
100 mA |
| Short Circuit Protection |
yes |
| Reverse Polarity Protection |
yes |
| Overload Protection |
yes |
Mechanical Data
| Housing Material |
Plastic, PBT |
| Connection |
Cable; 4-wire |
| Cable length (L) |
700 mm |
| Cable Jacket Material |
Plastic, PUR |
| Wire cross-section |
0.25 mm² |
| Weight |
30 g |
Safety-relevant Data
| MTTFd (EN ISO 13849-1) |
2,418.19 a |
General Data
| Scope of delivery |
1 × sensor |
