Technical Data
Inductive Data
| Switching Distance |
0.8 mm |
| Correction Factors Stainless Steel V2A/CuZn/Al |
0,68/0,45/0,36 |
| Mounting |
Flush |
| Mounting A/B/C/D in mm |
0/5/2,4/0 |
| Switching Hysteresis |
< 15 % |
Electrical Data
| Supply Voltage |
10 … 30 V DC |
| Current Consumption (Ub = 24 V) |
< 10 mA |
| Switching Frequency |
5 kHz |
| Temperature Drift |
< 10 % |
| Temperature Range |
-25 … 80 °C |
| Switching Output Voltage Drop |
< 1 V |
| Switching Output/Switching Current |
100 mA |
| Residual Current Switching Output |
< 100 µA |
| Short Circuit Protection |
yes |
| Reverse Polarity Protection |
yes |
| Overload Protection |
yes |
| Protection Class |
III |
Mechanical Data
| Housing Material |
Stainless steel, V2A (1.4305 / 303) |
| Sensing face |
Plastic, PA |
| Full Encapsulation |
yes |
| Degree of Protection |
IP67 |
| Connection |
Cable; 3-wire |
| Cable length (L) |
2 m |
| Cable Jacket Material |
PVC |
| Wire cross-section |
0.14 mm² |
| Weight |
32 g |
Safety-relevant Data
| MTTFd (EN ISO 13849-1) |
5,680.48 a |
Standards and certificates
