FI1.5-KH6.5E-ON6L-Q8 Inductive Sensor
Inductive Sensor, Metal smooth cylindrical housing d = 6.5 mm, Switching distance 1.5 mm, Flush, IP67, -25…70 °C, NPN NO, M8 connector
In Stock
$22.23
per unit
Applications: Sensors & I/O
Technical Data
| Supply voltage | 10 … 30 V DC |
| External dimensions | Φ 6.5 |
| Output status | NO |
| IP rating | IP67 |
| Sensing range | 1.5 mm |
| Connection | M8, 3-pin |
| Housing material | Stainless steel |
| Sensing surface material | PBT |
| Switching frequency | 1000 Hz |
| Load current | ≤ 200 mA |
| Ambient temperature | -25 … +70 ℃ |
| Output type | NPN |
| Mounting | Flush |
| Product size | Φ 6.5 x 60 mm |
