EA250-P24 Through-Beam Sensor
Through-Beam Sensor
In Stock
$88.30
per unit
Applications: Sensors & I/O
Description
These through-beam sensors work in combination with the LV250 controller. They can be freely positioned as desired. Thanks to their large working range, the devices demonstrate excellent functional reliability in highly contaminated environments.
Features at a Glance
- For connection to LV250 controller
- Functions reliably with severe contamination
- No interactive influence
Technical Data
Optical Data
| Light Source | Infrared Light |
| Service Life (T = +25 °C) | 100,000 h |
| Max. Ambient Light | 10,000 Lux |
| Opening Angle | 8 ° |
Electrical Data
| Sensor Type | Receiver |
| Temperature Drift | < 10 % |
| Temperature Range | -25 … 60 °C |
| Short Circuit Protection | yes |
| Reverse Polarity Protection | yes |
| Overload Protection | yes |
| Protection Class | III |
Mechanical Data
| Housing Material | Brass, nickel-plated |
| Full Encapsulation | yes |
| Degree of Protection | IP67 |
| Connection | Cable; 2-wire |
| Cable length (L) | 6 m |
| Cable Jacket Material | PVC |
| Weight | 159 g |
General Data
| Scope of delivery | 1 × initial start-up instructions 1 × MUTTER-M12-E001 hex nut 1 × sensor |
Output
| For connection to LV250 control module | yes |
Standards and certificates
     |
