ZVZG209 IR Longpass Filter for C mount lens
IR Longpass Filter
In Stock
$296.62
per unit
Description
IR long-pass filters are recommended when using infrared illumination. With image processing applications that use IR illumination, interfering ambient light is filtered out, making the application more robust.
Technical Data
Optical Data
| Usable wavelength range | 845 … 1,100 nm |
| Maximum transmission | ≥ 90 % |
| Half-value width FWHM | 830 nm |
| Tolerance | ± 10 nm |
Mechanical Data
| Mounting type, device-side | can be screwed |
| Material | Aluminum, painted Glass |
| Pane coating | anti-reflective |
| Filter Screw Size | M34 × 0.5 mm |
| Temperature Range | -40 … 300 °C |
| Surface quality | 40/20 |
| Weight | 5 g |
General Data
| Packaging unit | 1 Piece |
