ZDHL001 Connection Line M12 × 1; 5-pin, L-coding
Connection Line
In Stock
$171.92
per unit
Applications: Sensors & I/O
Description
Features at a Glance
- PUR, straight
- Halogen free
Technical Data
Electrical Data
| Rated current | 16 A |
Mechanical Data
| Connection 1 | Socket, straight |
| Connection mode 1 | M12 × 1, 5-pin, L-cod. |
| Connection 2 | stripped |
| Torque | M12: 0,6 Nm |
| Coding | L-coding |
| Cable length (L) | 10 m |
| Outer diameter (d) | 8.7 mm |
| Wire cross-section | 1.5 mm² |
| Degree of Protection | IP67 |
| Temperature Range | -5 … 70 °C |
| Cable Jacket Material | Plastic, PUR |
| Material Wire Insulation | PVC |
| Material Sleeve Nut | Brass, nickel-plated |
| Halogen-free | yes |
| Bending radius (fixed installation) | > 7,5 × d |
| Bending radius (used in motion) | > 10 × d |
| Weight | 1,350 g |
General Data
| Scope of delivery | 1 × connection line |
| Packaging unit | 1 Piece |
Pin assignment
 |
Connection Diagram
 |
