Z30M001 Mounting Console with Fixed Limit Stop for M30 × 1,5; Flush Mounting
Mounting Console with Fixed Limit Stop
In Stock
$59.24
per unit
Description
Features at a Glance
- Integrated, fixed limit stop for precise sensor positioning
- Time savings thanks to easy installation
- No reduction of the switching distance
- For M30 × 1,5, flush
Technical Data
Mechanical Data
| Material | Stainless steel, V2A (1.4305 / 303) Plastic, PBT |
| Mounting | Flush |
| Threaded sleeve tightening torque | max. 6 Nm |
| Clamp retainer tightening torque | 4 Nm |
| Weight | 105 g |
General Data
| Scope of delivery | 1 × mounting console |
| Packaging unit | 1 Piece |
| Use | for threaded housing |
Standards and certificates
 |
