Technical Data
Electrical Data
| Supply Voltage |
18 … 32 V |
| Min. Current Consumption |
< 25 mA |
| Max. Current Consumption |
< 500 mA |
| Temperature Range |
-25 … 60 °C |
| Reverse Polarity Protection |
yes |
| Supported PoE Standard |
IEEE802.3af, IEEE802.at |
| Supported PoE Classes |
Class 1, 2 |
| Protection Class |
III |
Mechanical Data
| Material |
Plastic |
| Full Encapsulation |
yes |
| Degree of Protection |
IP67 |
| Type of Connection Power |
M8 × 1; 4-pin |
| Type of Connection Ethernet |
M12 × 1; 4-pin |
| Type of Connection PoE |
M12 × 1; 8-pin, X-cod. |
| Cable length (L) |
1 m |
| Weight |
199 g |
General Data
| Scope of delivery |
1 × BEF-SET-41 mounting set
1 × initial start-up instructions
1 × midspan adapter |
| Packaging unit |
1 Piece |
Output
| Power Source Equipment for PoE |
yes |
Standards and certificates
Complementary Products
- Connection Cable ZAV51Rx0x
- Connection Line S60-xM, S61-xM
|
