VISION VX 2B LR WT
Watertight enclosure, Long Range, IP67, Auto-manual restart + EDM, Prewired 10 m lead
In Stock
$1,636.17
per unit
Applications: Safety Systems
Description
Type 2, SILCL 1, PL c, Cat. 2
Watertight enclosures allow Safety Light Curtains to be used in harsh working and outdoor environments
Integrated anti-condensation system
Hardware configuration: no programming necessary, easy to install and replace
What’s in the Box: Emitter, Receiver, Standard Fastening Brackets, Pre-Wired Connection Cable
Technical Data
Features
| Safety level | Type 2 – PL c |
| Protected height (mm) | 500 |
| Resolution (mm) | Multi-beams |
| Max. range (m) | 50 |
| Restart | Built-in – User selectable automatic or manual |
| Functioning system | Emitter / Receiver |
| Safety level (SIL / PL) | Type 2 – SILCL 1 – PL c – Cat. 2 |
| Operating temperature (°C) | 0 … 55 |
| Response time (ms) | 5 |
| Number of beams | 2 |
| Max. length of the connection cables (m) | 100 |
| Signalling | 7 segment display and LEDs for light curtain’s status and diagnostics |
| Safety output type | 2 fail-safe PNP (500 mA at 24 VDC) with protection against short circuit, overload and reverse polarity |
| MTTFD (ISO13849) years | 100 |
| PFHD (IEC 61508) | 8,97E-09 |
| Light curtain technical data | Refer to VX LR models table |
| Safety outputs | 2 OSSD PNP (500 mA at 24 VDC) |
| Safety functions | Integrated |
| Special versions | Watertight enclosure |
| Detection | Access control |
| Operating Range (m) | 18 or 50 selectable |
| Protective enclosures | Harsh working environments |
| Packaging dimensions HxLxW (mm) | 145 x 950 x 200 |
| Product class | C |
| Custom tariff | 85365019 |
Electrical data
| Power supply (VDC) | 24 ± 20% |
Mechanical data
| Overall height (mm) | 841 |
| Degree of protection | IP67 |
| Fastening | Set of 4 WFB ring brackets (included) |
| Max. water pressure (bar) | 40 |
