Technical Data
Mechanical Data
| Connection 1 |
Socket, straight |
| Connection mode 1 |
SUB D, 9-pin |
| Connection 2 |
Socket, angled
Plug, angled |
| Connection mode 2 |
M12 × 1, 8-pin |
| Torque |
M12: 0,6 Nm |
| Coding |
A-coding |
| Cable length (L) |
1.5 m |
| Outer diameter (d) |
4.4 mm |
| Wire cross-section |
0.25 mm² |
| Degree of Protection |
IP50 |
| Temperature Range |
-10 … 60 °C |
| Cable Jacket Material |
Plastic, PUR |
| Material Wire Insulation |
Plastic, PVC |
| Material Sleeve Nut |
Brass, nickel-plated |
| Screened |
yes |
| Weight |
99 g |
General Data
| Scope of delivery |
1 × line |
| Packaging unit |
1 Piece |
Standards and certificates
