P3PC341 Laser Distance Sensor Triangulation
Laser Distance Sensor
Applications: Sensors & I/O
Description
These laser distance sensors work with a fine blue light beam and a high-resolution CMOS line. They determine the distance between the sensor and the object by means of the triangulation principle. Thanks to the integrated TripleA technology, the sensors offer high precision, temperature stability and material independence. This means they deliver accurate results even with objects of different materials, colors and shapes, as well as in fluctuating light and temperature conditions. The blue laser light enables enhanced performance on challenging surfaces. Settings are entered via the easy-to-read OLED display or via Bluetooth using the weCon app.
Features at a Glance
- Analog output: 4…20 mA
- Wireless settings via Bluetooth
- Graphical display for easy operation
- Measured value independent of material, color and brightness
- Rugged aluminium housing
Technical Data
Optical Data
| Working Range | 60 … 660 mm |
| Measuring Range | 60 … 660 mm |
| Reproducibility maximum | 250 µm |
| Reproducibility: 1 Sigma | 25 µm |
| Linearity Deviation | 900 µm |
| Light Source | Laser (blue) |
| Wavelength | 405 nm |
| Service Life (T = +25 °C) | 100,000 h |
| Laser Class (EN 60825-1) | 2 |
| Max. Ambient Light | 5,000 Lux |
| Light Spot Diameter | see Table 1 |
Electrical Data
| Supply Voltage | 18 … 30 V DC |
| Current Consumption (Ub = 24 V) | < 70 mA |
| Measuring Rate | 2,500 /s |
| Response Time | < 0.5 ms |
| Temperature Drift | < 50 µm/K |
| Temperature Range | 0 … 60 °C |
| Analog Output | 4…20 mA |
| Short Circuit Protection | yes |
| Reverse Polarity Protection | yes |
| Overload Protection | yes |
| Interface | IO-Link V1.1 |
| IO-Link Version | 1.1 |
| IO-Link transmission speed | COM3 |
| Protection Class | III |
| FDA Accession Number | 2310698-000 |
Mechanical Data
| Setting Method | (OLED)/Bluetooth menu |
| Housing Material | Aluminum, anodised Plastic, ABS |
| Degree of Protection | IP67 |
| Connection | M12 × 1; 5-pin |
| Optic Cover | Plastic, PMMA |
| Weight | 71 g |
Safety-relevant Data
| MTTFd (EN ISO 13849-1) | 398.5 a |
General Data
| Scope of delivery | 1 × initial start-up instructions 1 × sensor |
Output
| Error Output | yes |
| Analog Output | yes |
| IO-Link | yes |
Adjustable parameters
| Output | Error Output Push-pull NPN PNP |
| Analog output | 0…10 V 4…20 mA |
| Circuit | NC NC/NO NO |
| Other parameters | Exposure time Laser light Switching hysteresis Teach-in mode Off-delay On-delay |
| All other parameters can be found in the product documentation. |
Standards and certificates
       |
Table 1
| Working Distance | 60 mm | 360 mm | 660 mm |
| Light Spot Diameter | 1,5 mm | 1 mm | 0,5 mm |
Connection Diagram
 |
Ctrl. Panel
|
5a = Switching Status Indicator, O1
68 = Power LED 7c = Analog Output Indicator, AO 20 = Enter key 60 = display |
