OSM40-KL800CB6Q12.1/IO Distance Sensor
Distance Sensor, OSM40-Series, Laser Distance Sensor (Triangulation), Red laser, Operating range 150…800 mm, Resolution 0.1 mm, NPN or PNP, IO-Link, 10…30V DC, -10…50°C, IP67, M12 5-pin connector
In Stock
$254.75
per unit
Applications: Sensors & I/O
Technical Data
| Detection method | CMOS ranging |
| Sensing range | 150 … 800 mm |
| Light source | Red laser / Class 2 |
| Spot size | 1 mm @ 400 mm |
| Resolution | 0.1 mm |
| Repeatability | 0.5 mm @ 150 … 400 mm & 1 mm @ 400 … 600 mm & 3 mm @ 600 … 800 mm |
| Output type | NPN / PNP & IO-Link |
| Output status | L.O / D.O |
| Response time | 1.5 ms / 5 ms / 10 ms |
| Supply voltage | 10 … 30 V DC |
| Load current | ≤ 150 mA |
| Ambient temperature | -10 … +50 ℃ |
| Housing Material | Stainless steel |
| Connection type | M12, 5-pin |
| Connection | Connector |
| IP rating | IP67 |
| Anti-ambient light | ≤ 3000 lux |
