OS4-AK30DN6 Photoelectric Sensor
Photoelectric Sensor, OS4-Series, Diffused fixed BGS, Red beam, Operating range 5…30 mm, NPN, D.O, 10…30V DC, -10…55°C, Switching frequency 800 Hz, IP67, Cable 2 m
In Stock
$60.21
per unit
Applications: Sensors & I/O
Technical Data
| Output type | NPN |
| Connection type | 2 m, PVC |
| Output status | D.O |
| Switching frequency | 800 Hz |
| Supply voltage | 10 … 30 V DC |
| Anti-ambient light | ≤ 10000 lux |
| IP rating | IP67 |
| Special characteristics | Fixed distance BGS |
| Connection | Cable |
| Housing material | PC + PBT |
| Load current | ≤ 50 mA |
| Ambient temperature | -10 … +55 ℃ |
| Detection method | BGS Diffused |
| Light source | Red LED |
| Spot size | 8 mm @ 30 mm |
| Sensing range | 5 … 30 mm |
