OP18-S6Q Photoelectric Sensor
Photoelectric Sensor, OP18-Series, Opposed, Emitter, Infrared beam, Operating range 10 m, 10…30V DC, -25…65°C, IP67, M12 4-pin connector
In Stock
$16.72
per unit
Applications: Sensors & I/O
Technical Data
| Detection method | Opposed (Emitter) |
| Sensing range | 10 m |
| Light source | Infrared LED |
| Spot size | 90 mm @ 1 m |
| Supply voltage | 10 … 30 V DC |
| Connection type | M12, 4-pin |
| Ambient temperature | -25 … +65 ℃ |
| IP rating | IP67 |
| Connection | Connector |
| Housing material | PC + PBT |
| Anti-ambient light | ≤ 5000 lux |
