OP12-EDN6 Photoelectric Sensor
Photoelectric Sensor, OP12-Series, Opposed, Receiver, Infrared beam, Operating range 5 m, NPN, D.O, 10…30V DC, -10…50°C, Switching frequency 100 Hz, IP67, Cable 2 m
In Stock
$20.84
per unit
Applications: Sensors & I/O
Technical Data
| Connection type | 2 m, PVC |
| Load current | ≤ 50 mA |
| Detection method | Opposed (Receiver) |
| Sensing range | 5 m |
| Output type | NPN |
| IP rating | IP67 |
| Switching frequency | 100 Hz |
| Supply voltage | 10 … 30 V DC |
| Connection | Cable |
| Anti-ambient light | ≤ 10000 lux |
| Housing material | PC + PMMA |
| Ambient temperature | -10 … +50 ℃ |
| Output status | D.O |
