NI8-M18E-OSA3L Inductive Sensor
Inductive Sensor, Threaded cylindrical long housing M18, Switching distance 8 mm, Non-flush, IP67, -25…70 °C, AC NO, 2 m cable
In Stock
$29.64
per unit
Applications: Sensors & I/O
Technical Data
| Switching frequency | 40 Hz |
| Sensing surface material | PBT |
| Ambient temperature | -25 … +70 ℃ |
| Housing material | Nickel-plated brass |
| Supply voltage | 20 … 250 V AC |
| Sensing range | 8 mm |
| Load current | ≤ 200 mA |
| Output status | NO |
| External dimensions | M18 x 1 |
| Output type | AC |
| Mounting | Non-flush |
| Product size | M18 x 60 mm |
| Connection | Cable |
| Cable length | 2 m |
| Cable type | PVC |
| IP rating | IP67 |
