NI8-M18E-OD6L Inductive Sensor
Inductive Sensor, Threaded cylindrical long housing M18, Switching distance 8 mm, Non-flush, IP67, -25…70 °C, DC NO, 2 m cable
In Stock
$27.79
per unit
Applications: Sensors & I/O
Technical Data
| Ambient temperature | -25 … +70 ℃ |
| Cable type | PVC |
| Sensing range | 8 mm |
| Connection | Cable |
| IP rating | IP67 |
| Sensing surface material | PBT |
| Load current | ≤ 100 mA |
| Output status | NO |
| Housing material | Nickel-plated brass |
| Switching frequency | 500 Hz |
| Supply voltage | 10 … 30 V DC |
| External dimensions | M18 x 1 |
| Output type | DC |
| Mounting | Non-flush |
| Product size | M18 x 70 mm |
| Cable length | 2 m |
