NI8-AM18-CD6L-Q12 Inductive Sensor
Inductive Sensor, All metal housing, Threaded cylindrical housing M18, Switching distance 8 mm, Non-flush, IP67, -25…70 °C, 2-wire DC, M12 connector
In Stock
$45.95
per unit
Applications: Sensors & I/O
Technical Data
| Connection | M12, 4-pin |
| Output status | NC |
| Sensing range | 8 mm |
| IP rating | IP67 |
| Output type | DC |
| Supply voltage | 10 … 30 V DC |
| Product size | M18 x 72 mm |
| Sensing surface material | Stainless steel |
| Switching frequency | 100 Hz |
| Load current | ≤ 100 mA |
| Housing material | Stainless steel |
| Ambient temperature | -25 … +70 ℃ |
| External dimensions | M18 x 1 |
| Mounting | Non-flush |
