NI70-W80-VA41L-Q/TB40 Inductive Sensor
Inductive Sensor, Rectangular housing W80, Switching distance 70 mm, Non-flush, IP67, -40…70 °C, 20…250V/AC/DC 4-wire NO+NC, Screw terminal
In Stock
$108.85
per unit
Applications: Sensors & I/O
Technical Data
| Mounting | Non-flush |
| Sensing range | 70 mm |
| Connection | Terminal |
| Housing material | PA |
| Sensing surface material | PA |
| IP rating | IP67 |
| Load current | DC ≤ 100 mA / AC ≤ 200 mA |
| Switching frequency | 20 Hz |
| Supply voltage | 20 … 250 V AC/DC |
| Ambient temperature | -40 … +70 ℃ |
| Output status | NO + NC |
| Output type | DC / AC |
| External dimensions | Square |
| Product size | 80 x 80 x 40 mm |
