NI4-M12E-OP6L Inductive Sensor
Inductive Sensor, Threaded cylindrical long housing M12, Switching distance 4 mm, Non-flush, IP67, -25…70 °C, PNP NO, 2 m cable
In Stock
$21.31
per unit
Applications: Sensors & I/O
Technical Data
| Supply voltage | 10 … 30 V DC |
| Sensing range | 4 mm |
| Housing material | Nickel-plated brass |
| Sensing surface material | PBT |
| Switching frequency | 800 Hz |
| Ambient temperature | -25 … +70 ℃ |
| Load current | ≤ 200 mA |
| Output status | NO |
| Output type | PNP |
| External dimensions | M12 x 1 |
| Mounting | Non-flush |
| Product size | M12 x 60.2 mm |
| Connection | Cable |
| IP rating | IP67 |
| Cable type | PVC |
| Cable length | 2 m |
