NI30-W40-CN6L-Q12/TB40 Inductive Sensor
Inductive Sensor, Rectangular housing W40, Switching distance 30 mm, Non-flush, IP67, -40…70 °C, DC NC NPN, 10…30 V DC, M12 connector
In Stock
$47.24
per unit
Applications: Sensors & I/O
Technical Data
| Mounting | Non-flush |
| Connection | M12, 4-pin |
| Product size | 66 x 40 x 40 mm |
| Output type | NPN |
| Sensing range | 30 mm |
| Housing material | PA |
| Sensing surface material | PA |
| Switching frequency | 100 Hz |
| Supply voltage | 10 … 30 V DC |
| Ambient temperature | -40 … +70 ℃ |
| Load current | ≤ 200 mA |
| Output status | NC |
| External dimensions | Square |
| IP rating | IP67 |
