NI20-WL40-CP6L-Q/TB40 Inductive Sensor
Inductive Sensor, Rectangular housing WL40, Switching distance 20 mm, Non-flush, IP67, -40…70 °C, PNP NC, screw terminals
In Stock
$64.38
per unit
Applications: Sensors & I/O
Technical Data
| Mounting | Non-flush |
| Housing material | PA |
| IP rating | IP67 |
| Sensing range | 20 mm |
| Sensing surface material | PA |
| Ambient temperature | -40 … +70 ℃ |
| Connection | Terminal |
| Output status | NC |
| Output type | PNP |
| External dimensions | Square |
| Product size | 115 x 40 x 40 mm |
| Load current | ≤ 200 mA |
| Switching frequency | 150 Hz |
| Supply voltage | 10 … 30 V DC |
