NI12-G18-OD6L-Q12 Inductive Sensor
Inductive Sensor, Threaded cylindrical housing M18, Switching distance 12 mm, Non-flush, IP68, -30…85 °C, 2-wire DC, M12 connector
In Stock
$25.94
per unit
Applications: Sensors & I/O
Technical Data
| Connection | M12, 4-pin |
| IP rating | IP68 |
| External dimensions | M18 x 1 |
| Sensing range | 12 mm |
| Sensing surface material | PBT |
| Housing material | Nickel-plated brass |
| Switching frequency | 350 Hz |
| Supply voltage | 10 … 30 V DC |
| Ambient temperature | -30 … +85 ℃ |
| Load current | ≤ 100 mA |
| Output status | NO |
| Output type | DC |
| Mounting | Non-flush |
| Product size | M18 x 77 mm |
