Technical Data
Inductive Data
| Switching Distance |
25 mm |
| Standard Target |
75 × 75 mm |
| Correction Factors Stainless Steel V2A/CuZn/Al |
0,60/1,00/0,85 |
| Mounting |
Non-flush |
| Mounting A/B/C/D in mm |
10/120/50/20 |
| Mounting B1 in mm |
0…40 |
| Switching Hysteresis |
< 10 % |
| Use |
With INTT2xx analysis module |
Electrical Data
| Sensor head temperature range |
-10 … 250 °C |
| Service Life (T = +200 °C) |
100,000 h |
| Service Life (T = +250 °C) |
60,000 h |
Mechanical Data
| Sensing face |
Plastic, PEEK |
| Sensor head material |
Stainless steel, V2A (1.4305 / 303) |
| Degree of protection, sensor head |
IP50 |
| Degree of protection of the plug |
IP50 |
| PWIS-free |
yes |
| Weight |
396 g |
General Data
| Scope of delivery |
1 × initial start-up instructions
1 × sensor head |
Function
| Programmable switching distance |
15/20/25 mm |
Output
| IO-Link |
yes |
| Error Output |
yes |
| PNP NO |
yes |
Standards and certificates
Complementary Products
- Inductive analysis module
- IO-Link Master
- Software
|
