FI7-Q25-CSA3L Inductive Sensor
Inductive Sensor, Rectangular housing Q25, Switching distance 7 mm, Flush, IP67, -25…70 °C, 2-wire AC NC, Cable 2 m
In Stock
$25.48
per unit
Applications: Sensors & I/O
Technical Data
| Output status | NC |
| Mounting | Flush |
| Ambient temperature | -25 … +70 ℃ |
| Sensing range | 7 mm |
| Housing material | ABS + PBT |
| Sensing surface material | ABS + PBT |
| Switching frequency | 300 Hz |
| Supply voltage | 20 … 250 V AC |
| Load current | ≤ 200 mA |
| Output type | AC |
| External dimensions | Square |
| Product size | 38 x 25 x 25 mm |
| Connection | Cable |
| Cable type | PVC |
| Cable length | 2 m |
| IP rating | IP67 |
