FI2-M12S-BP6L-Q12 Inductive Sensor
Inductive Sensor, Short threaded cylindrical housing M12, Switching distance 2 mm, Flush, IP67, -25…70 °C, PNP NO+NC, M12 connector
In Stock
$24.55
per unit
Applications: Sensors & I/O
Technical Data
| Connection | M12, 4-pin |
| Ambient temperature | -25 … +70 ℃ |
| IP rating | IP67 |
| Sensing surface material | PBT |
| Housing material | Nickel-plated brass |
| Sensing range | 2 mm |
| Product size | M12 x 42 mm |
| Load current | ≤ 200 mA |
| Output status | NO + NC |
| Switching frequency | 1000 Hz |
| Supply voltage | 10 … 30 V DC |
| External dimensions | M12 x 1 |
| Mounting | Flush |
| Output type | PNP |
