FI2-M12E-CSA3L-Q12 Inductive Sensor
Inductive Sensor, Threaded cylindrical long housing M12, Switching distance 2 mm, Flush, IP67, -25…70 °C, AC NC, M12 connector
In Stock
$25.94
per unit
Applications: Sensors & I/O
Technical Data
| Switching frequency | 40 Hz |
| Sensing surface material | PBT |
| IP rating | IP67 |
| Housing material | Nickel-plated brass |
| Sensing range | 2 mm |
| Ambient temperature | -25 … +70 ℃ |
| Supply voltage | 20 … 250 V AC |
| Connection | M12, 4-pin |
| Load current | ≤ 200 mA |
| Output status | NC |
| External dimensions | M12 x 1 |
| Output type | AC |
| Mounting | Flush |
| Product size | M12 x 62 mm |
