FI2-AM12-CN6L Inductive Sensor
Inductive Sensor, All metal housing, Threaded cylindrical housing M12, Switching distance 2 mm, Flush, IP67, -25…70 °C, NPN NC, Cable 2 m
In Stock
$41.69
per unit
Applications: Sensors & I/O
Technical Data
| Connection | Cable |
| Cable type | PVC |
| Cable length | 2 m |
| IP rating | IP67 |
| Sensing range | 2 mm |
| Housing material | Stainless steel |
| Sensing surface material | Stainless steel |
| Switching frequency | 200 Hz |
| Supply voltage | 10 … 30 V DC |
| Ambient temperature | -25 … +70 ℃ |
| Load current | ≤ 200 mA |
| Output status | NC |
| Output type | NPN |
| External dimensions | M12 x 1 |
| Mounting | Flush |
| Product size | M12 x 51 mm |
