FI10-AM30-CSA3L-Q12 Inductive Sensor
Inductive Sensor, All metal housing, Threaded cylindrical housing M30, Switching distance 10 mm, Flush, IP67, -25…70 °C, 2-wire AC NC, M12 connector
In Stock
$74.11
per unit
Applications: Sensors & I/O
Technical Data
| Connection | M12, 4-pin |
| Housing material | Stainless steel |
| Ambient temperature | -25 … +70 ℃ |
| Load current | ≤ 200 mA |
| Sensing range | 10 mm |
| Sensing surface material | Stainless steel |
| Switching frequency | 40 Hz |
| Supply voltage | 20 … 250 V AC |
| Output status | NC |
| Output type | AC |
| External dimensions | M30 x 1 |
| Mounting | Flush |
| Product size | M30 x 68 mm |
| IP rating | IP67 |
