FC8-KM18-OP6L-Q12 Capacitive Sensor
Capacitive Sensor, Stainless steel threaded cylindrical housing KM18, Switching distance 8 mm, Flush, IP67, -25…70 °C, PNP NO, M12 3-pole
In Stock
$30.11
per unit
Applications: Sensors & I/O
Technical Data
| Load current | ≤ 200 mA |
| Sensing range | 8 mm |
| External dimensions | M18 x 1 |
| Sensing surface material | PBT |
| Switching frequency | 15 Hz |
| IP rating | IP67 |
| Product size | M18 x 81 mm |
| Housing material | Stainless steel |
| Mounting | Flush |
| Connection | M12, 4-pin |
| Output status | NO |
| Ambient temperature | -25 … +70 ℃ |
| Output type | PNP |
| Supply voltage | 10 … 30 V DC |
