EOS4 1051 X WTHF
Heated watertight enclosure, IP69K, Ecolab, Auto-manual restart + EDM, Prewired 10 m lead
In Stock
$3,680.35
per unit
Applications: Safety Systems
Description
Type 4, SIL 3, SILCL 3, PL e, Cat. 4
Watertight enclosures allow Safety Light Curtains to be used in harsh working environments with exposure to water jets and steam
The use of inert and non-toxic components allow WTF and WTHF enclosures to be used in the Food & Beverage industry, where frequent wash down procedures are required
Integrated anti-condensation system
Hardware configuration: no programming necessary, easy to install and replace
What’s in the Box: Emitter, Receiver, Standard Fastening Brackets, Pre-Wired Connection Cable
Technical Data
Features
| Safety level | Type 4 – PL e |
| Protected height (mm) | 1060 |
| Resolution (mm) | 14 |
| Controlled height (mm) | 1050 |
| Max. range (m) | 5 |
| Restart | Built-in – User selectable automatic or manual |
| Functioning system | Emitter / Receiver |
| Safety level (SIL / PL) | Type 4 – SIL 3 – SILCL 3 – PL e – Cat. 4 |
| Operating temperature (°C) | – 25 … 50 |
| Response time (ms) | 14,5 |
| Number of beams | 105 |
| Max. length of the connection cables (m) | 100 |
| Signalling | LEDs for light curtain’s status and diagnostics |
| Safety output type | 2 fail-safe PNP (400 mA at 24 VDC) with protection against short circuit, overload and reverse polarity |
| Connections | Cable output |
| MTTFD (ISO13849) years | 100 |
| PFHD (IEC 61508) | 2,49E-08 |
| Materials suitable for food applications | Yes |
| Light curtain technical data | Refer to EOS4 X models table |
| Safety outputs | 2 OSSD PNP (400 mA at 24 VDC) |
| Safety functions | Integrated |
| Special versions | Food and beverage, Heated, Watertight enclosure |
| Detection | Finger |
| Operating Range (m) | Selectable: 0 … 2 m – low range / 0 … 5 m – high range |
| Protective enclosures | Food industry IP69K |
| Packaging dimensions HxLxW (mm) | 145 x 1360 x 200 |
| Product class | C |
| Custom tariff | 85365019 |
Electrical data
| Power supply (VDC) | 24 ± 20% |
Mechanical data
| Overall height (mm) | 1237 |
| Degree of protection | IP69K |
| Fastening | Set of 4 ring brackets (included) |
| Diameter (mm) | 56 |
| Max. water pressure (bar) | 80 . . . 100 |
