ECS-FC12.5-2.2-10/10/VT Y-Splitter
Y-Splitter, M12 A-code 5-pin Straight Female, to M12 A-code 3-pin Straight Male,and 2-pole Cable, with PVC grey jacket 0.34mm² (22 AWG) Cable , 10 m/10 m
In Stock
$33.40
per unit
Applications: Sensors & I/O
Technical Data
| Product type | Y-Splitter |
| Termination type | Y-Splitter |
| Head 1 Type | M12 |
| Head 1 Coding | A-code |
| Head 1 Number of contacts | 5 |
| Head 1 Shape | Straight |
| Head 1 Gender | Female |
| Head 2 Type | M12 |
| Head 2 Coding | A-code |
| Head 2 Number of contacts | 3 |
| Head 2 Shape | Straight |
| Head 2 Gender | Male |
| Head 3 Type | Cable |
| Head 3 Number of contacts | 2 |
| The head material | TPU |
| Nut/bolt material | Zinc die casting |
| Coating contact material | Gold-plated copper |
| Material contact | TPU |
| Rated voltage | 60 V AC/DC |
| Rated current | 4 A |
| Wire cross-section | 0.34 mm² (22 AWG) |
| LED indicator | NO |
| Cable jacket material | PVC |
| Cable jacket color | grey |
| Wire insulation material | PVC |
| Wire insulation color | BN,BU,BK |
| Shielded/Unshielded | No |
| Drag chain | Fixed installation |
| Resistant to welding sparks | NO |
| Flex & Torsion | NO |
| IP rating | IP67 |
| Cable length | 10 m |
