| Flash |
4 GB |
| RAM |
1 GB |
| CPU |
Quad-core RISC |
| Memory Card Type |
microSD x 1 |
| USB Host |
USB 2.0 x 1 |
| Ethernet Port |
LAN 1: 10/100/1000 Base-T x 1nLAN 2: 10/100 Base-T x 1 |
| COM Port |
COM1: RS-232 2WnnCOM2: RS-485 2W/4WnnCOM3: RS-485 2W |
| HDMI Output |
N/A |
| Recommended Resolutions(Please use these recommended screen resolutions to avoid compatibility issues.) |
N/A |
| WiFi |
N/A |
| RS-485 Dual Isolation |
N/A |
| CAN Bus |
N/A |
| Audio Output |
N/A |
| Input Power |
24±20% VDC |
| Power Isolation |
Built-in |
| Power Consumption |
850mA@24VDC |
| Voltage Resistance |
500VAC (1 min.) |
| Isolation Resistance |
Exceed 50MΩ at 500VDC |
| Enclosure |
Plastic |
| Dimensions WxHxD |
29.8 x 130 x 115 mm |
| Weight |
Approx. 0.24 kg |
| Mount |
35mm DIN rail mounting |
| PCB Coating |
Yes |
| Protection Structure |
IP20 |
| Storage Temperature |
-20° ~ 60°C (-4° ~ 140°F) |
| Operating Temperature |
0° ~ 50°C (32° ~ 122°F) |
| Relative Humidity |
10% ~ 90% (non-condensing) |
| Altitude |
3,000 m |
| Vibration Endurance |
10 to 25Hz (X, Y, Z direction 2G 30 minutes) |
| CE |
CE marked |
| UL |
cULus Listed |
| Weincloud |
EasyAccess 2.0 (Optional)nDashboard (Optional) |
| CODESYS |
Optional |
