| Flash |
256 MB |
| RAM |
256 MB |
| CPU |
Quad-core RISC |
| Memory Card Type |
microSD x 1 |
| USB Host |
USB 2.0 x 1 |
| Ethernet Port |
10/100 Base-T x 1 |
| COM Port |
COM1: RS-232 2WnnCOM2: RS-485 2W/4WnnCOM3: RS-485 2W |
| WiFi |
IEEE 802.11 b/g/nn802.11b: max 19.52 dBmn802.11g: max 15.35 dBmn802.11n: max 15.28 dBm |
| RS-485 Dual Isolation |
N/A |
| CAN Bus |
N/A |
| Audio Output |
N/A |
| Input Power |
24±20%VDC |
| Power Isolation |
Built-in |
| Power Consumption |
450mA@24VDC |
| Voltage Resistance |
500VAC (1 min.) |
| Isolation Resistance |
Exceed 50MΩ at 500VDC |
| Enclosure |
Plastic |
| Dimensions WxHxD |
27 x 130 x 115 mm |
| Weight |
Approx. 0.18 kg |
| Mount |
35mm DIN rail mounting |
| PCB Coating |
Yes |
| Protection Structure |
IP20 |
| Storage Temperature |
-20° ~ 70°C (-4° ~ 158°F) |
| Operating Temperature |
-20° ~ 55°C (-4° ~ 131°F) |
| Relative Humidity |
10% ~ 90% (non-condensing) |
| Altitude |
3,000 m |
| Vibration Endurance |
10 to 25Hz (X, Y, Z direction 2G 30 minutes) |
| CE |
CE marked |
| UL |
cULus Listed |
| Weincloud |
EasyAccess 2.0 (Built-in) |
