233-437-204 Glass Fiber-Optic Cable Through-Beam Mode
Glass Fiber-Optic Cable
In Stock
$574.62
per unit
Applications: Sensors & I/O
Description
Glass fiber optic cables are very flexible and can be used in applications with less space. Especially in applications with hot environment the metal casing fiber optic cables are the answer.
Features at a Glance
- A broad range of applications are possible due to the modular system design
- Stock types deliverable at short notice
Technical Data
Optical Data
| Fiber Bundle Diameter | 2.3 mm |
| Range with Sensor Type U_87__ | 1,800 mm |
| Range with Sensor Type U_88__ | 1,800 mm |
| Range with Sensor Type U_66__ | 1,000 mm |
| Range with Sensor Type U_55__ | 500 mm |
| Opening Angle | 68 ° |
| Fiber | Step Index |
| Fiber Diameter | 62 µm |
Mechanical Data
| Temperature Range | -60 … 180 °C |
| Bending Radius | 25 mm |
| Fiber-Optic Length L | 1 m |
| Jacket Material | Metal-Silicone |
| End sleeve shape | Angled |
| Material End Sleeve | Stainless Steel |
| End Sleeve No. | 37 |
| Light Emission | sidewise |
| Weight | 183 g |
General Data
| Scope of delivery | 1 × optical mount for universal optics M 1 × UEM18KU-02 sleeve nut 2 × fiber-optic cables |
| Packaging unit | 2 Pieces |
